Variable Capacity Tank (VCT)

The Variable Capacity Tank (VCT)—also known as a Closed Top Tank—is ideal for wineries seeking both versatility and precision. When wine is not protected by a lid and airlock, it risks oxidation and contamination. The VCT mitigates these risks with its floating lid and air-sealed system, allowing winemakers to safely ferment varying batch sizes without compromising quality.

Constructed from premium SS304 stainless steel, the tank features a polished internal and external surface (roughness ≤ 0.6 μm) for maximum cleanliness and sanitation. Every joint is 100% TIG welded, ground smooth, and surface passivated to ensure long-term durability and corrosion resistance.

Key design features include a flat 3% slope bottom for effective drainage, four sturdy legs with adjustable feet for stability, and a 466 mm high dimple cooling jacket (1.5 mm thick) with 1” NPT glycol inlet and outlet for precise temperature control. The floating lid with European-made gasket and lifting system, combined with a high-quality air pump, provides adjustable capacity and airtight protection.

Convenience and usability are enhanced with a side rectangular manhole (435×335 mm) for easy access, air vent (2”), drainage and outlet ports (2” with valve and clamp), racking arm, ½” sample valve, and two lifting lugs for handling.

Because winemakers only get one chance per harvest, the Variable Capacity Tank ensures that every batch is protected, consistent, and high-quality—whether used for small-lot fermentation or full-scale winery operations.

**Quality Assurance in Brewing**

At XG Machinery, we take pride in delivering top-tier solutions tailored specifically for the brewing industry. Our experienced sales and customer support teams are dedicated to ensuring that every brewery project not only meets but exceeds your expectations while aligning with your unique brewing requirements. We understand the significance of budgets and production timelines in the brewing sector, and we are committed to delivering results that matter.

Recognizing the individuality of each brewery, we engage in thorough consultations with our clients during the equipment procurement process. This collaborative approach helps us determine the ideal size, configuration, and fittings for your new brewing equipment. Following installation, our team works closely with yours to commission the brewing equipment, ensuring a seamless production process that consistently delivers the desired taste and yield with every batch.

**Internationally Recognized Quality Certifications**

We have implemented an efficient ERP management system and successfully passed rigorous quality audits to attain internationally recognized certifications highly esteemed in the brewing industry.

**Technical Support**

XG Machinery offers ongoing support for all our equipment. You can rely on us to provide information and assistance for your brewing processes. You can access resources on our website or contact us at any time for support, questions, or feedback. We warmly welcome your inquiries.

**On-Time and On-Budget Delivery**

We understand that acquiring new brewing equipment can be a significant investment and a complex process. At XG Machinery, our commitment to excellence extends beyond manufacturing. We take great pride in our ability to deliver equipment punctually and within the designated budget. Our dedicated project management team maintains regular communication with you, providing weekly updates on your project's status, complete with actual images of your equipment in the manufacturing pipeline. XG is a trusted name in the world of brewing.
